Volume pricing
- 1+ pcs$0.94
- 10+ pcs$0.89
- 100+ pcs$0.84
- 500+ pcs$0.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Safety Approval
- CUL; GL; IEC; KEMA; UL
- Contact Materials
- Copper
- Currentiec
- 32A
- Kurşunsuz Kodu
- yes
- Number Of Ways
- 4
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 9mm
- Onay Kuruluşu
- CB, CSA, UL, VDE
- Voltageiec
- 500V
- Renk
- Gray
- Tip
- Feed Through
- Montaj
- Through Hole
- Akım Değeri
- 32A
- Nem Hassasiyeti (MSL)
- Not Applicable
- Parça Durumu
- Active
- Wire Gauge Or Range Awg
- 10-26 AWG
- Sıra Sayısı
- 1
- Yayın Yılı
- 2008
- Genişlik
- 6.2mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.14-6mm2
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Lead Free
- Pozisyon Sayısı
- 4
- Material Insulation
- Polyamide (PA), Nylon
- Weight
- 17.600008g
- Gerilim
- 150V
- Seri
- CLIPLINE UT
- Akım
- 30A
- Number Of Levels
- 1
- Terminal Stili
- Screw
- Number Of Decks
- 1
- ECCN Kodu
- EAR99
- Wirecable Gauge
- 10 AWG
- Nominal Gerilim
- 500V
- Uzunluk
- 65.4mm
- Wire Gauge Max
- 26 AWG
- Max Current Rating
- 39A
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 10 AWG
