Specifications
- Akım Değeri
- 101A
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Or Range Awg
- 4-16 AWG
- Sıra Sayısı
- 1
- Wire Gauge Or Range Mm
- 1.5-25mm2
- Flammability Rating
- UL94 V-0
- Genişlik
- 12mm
- Yayın Yılı
- 2008
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Lead Free
- Kurşunsuz Kodu
- yes
- Currentiec
- 76A
- Safety Approval
- CB; CSA; CUL; GL; IEC; KEMA
- Onay Kuruluşu
- CSA, UL, VDE, cULus
- Number Of Poles
- 2
- Number Of Ways
- 2
- Stripping Length
- 14mm
- RoHS Durumu
- RoHS Compliant
- Tip
- Feed Through
- Renk
- Gray
- Voltageiec
- 1000V
- Montaj
- Through Hole
- Voltage Rated Dc
- 800V
- HTS Kodu
- 8536.69.40.40
- Nominal Gerilim
- 1kV
- Terminal Width
- 12.2mm
- Uzunluk
- 55.5mm
- Max Current Rating
- 101A
- Wire Gauge Max
- 16 AWG
- Maks. Çalışma Sıcaklığı
- 110°C
- Material Flammability Rating
- UL94 V-0
- Min. Çalışma Sıcaklığı
- -50°C
- Wire Gauge Min
- 4 AWG
- Weight
- 30.080006g
- Material Insulation
- Polyamide (PA), Nylon
- Akım
- 85A
- Additional Feature
- STANDARD: UL 94V-0, PA, SAFETY APPROVAL: UL; VDE
- Seri
- CLIPLINE UT
- Gerilim
- 600V
