Volume pricing
- 1+ pcs$0.98
- 10+ pcs$0.92
- 100+ pcs$0.87
- 500+ pcs$0.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 7 Weeks
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Mm
- 0.5-16mm2
- Genişlik
- 10.2mm
- Flammability Rating
- UL94 V-0
- Yayın Yılı
- 2008
- Wire Gauge Or Range Awg
- 6-20 AWG
- Akım Değeri
- 76A
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 55mm
- Number Of Poles
- 2
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 10mm
- Tip
- Feed Through
- Voltageiec
- 1000V
- Renk
- Blue
- Kurşunsuz Kodu
- yes
- Currentiec
- 57A
- Wire Gauge Min
- 6 AWG
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Polyamide
- Wire Gauge Max
- 20 AWG
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 1kV
- HTS Kodu
- 8536.69.40.40
- Uzunluk
- 47.7mm
- Wirecable Gauge
- 6 AWG
- Terminal Stili
- Screw
- ECCN Kodu
- EAR99
- Akım
- 65A
- Gerilim
- 600V
- Seri
- CLIPLINE UT
- Number Of Levels
- 1
- Material Insulation
- Polyamide (PA), Nylon
- Weight
- 16.919988g
