Volume pricing
- 1+ pcs$0.61
- 10+ pcs$0.58
- 100+ pcs$0.55
- 500+ pcs$0.51
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Maks. Çalışma Sıcaklığı
- 110°C
- Yükseklik
- 55mm
- Additional Feature
- PA, UL 94V-0
- Akım
- 50A
- Sıra Sayısı
- 2
- Parça Durumu
- Active
- Orientation
- Straight
- Nominal Gerilim
- 1kV
- Number Of Levels
- 1
- Seri
- CLIPLINE UT
- ECCN Kodu
- EAR99
- Yayın Yılı
- 2007
- Number Of Poles
- 2
- Terminal Stili
- Screw
- Kurşunsuz Kodu
- yes
- Stripping Length
- 10mm
- Wirecable Gauge
- 8 AWG
- Safety Approval
- UL; VDE; CSA
- Housing Material
- Polyamide
- Genişlik
- 8.2mm
- Akım Değeri
- 41A
- Wire Gauge Max
- 24 AWG
- Fabrika Tedarik Süresi
- 7 Weeks
- Radyasyon Dayanımı
- No
- Renk
- Blue
- Tip
- Feed Through
- Currentiec
- 41A
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Max Current Rating
- 57A
- Voltageiec
- 1000V
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Wire Gauge Or Range Awg
- 8-24 AWG
- Wire Gauge Min
- 24 AWG
- Min. Çalışma Sıcaklığı
- -50°C
- Nem Hassasiyeti (MSL)
- Not Applicable
- Material Flammability Rating
- UL94 V-0
- Number Of Ways
- 2
