Volume pricing
- 1+ pcs$0.44
- 10+ pcs$0.42
- 100+ pcs$0.39
- 500+ pcs$0.37
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltage Rated Dc
- 800V
- Safety Approval
- UL; CSA
- Housing Material
- Polyamide
- Akım Değeri
- 32A
- Genişlik
- 6.2mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Wire Gauge Max
- 26 AWG
- Orientation
- Straight
- Number Of Levels
- 1
- Seri
- CLIPLINE UT
- Contact Materials
- Copper
- Parça Durumu
- Active
- Sıra Sayısı
- 2
- Akım
- 30A
- Maks. Çalışma Sıcaklığı
- 110°C
- Yükseklik
- 55mm
- Terminal Stili
- Screw
- Number Of Poles
- 2
- Wirecable Gauge
- 10 AWG
- Stripping Length
- 9mm
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2008
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 1kV
- HTS Kodu
- 8536.69.40.40
- Material Flammability Rating
- UL94 V-0
- Gerilim
- 600V
- Max Supply Voltage
- 1kV
- Weight
- 8.969988g
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Depth
- 6.2mm
- Uzunluk
- 47.7mm
- Voltageiec
- 1000V
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Max Current Rating
- 41A
- Wire Gauge Or Range Mm
- 0.14-6mm2
- Material Insulation
- Polyamide (PA), Nylon
- Renk
- Blue
- Currentiec
- 32A
