Volume pricing
- 1+ pcs$0.34
- 10+ pcs$0.32
- 100+ pcs$0.30
- 500+ pcs$0.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Genişlik
- 5.2mm
- Akım Değeri
- 32A
- Wire Gauge Max
- 26 AWG
- Nominal Gerilim
- 1kV
- Number Of Levels
- 1
- Maks. Çalışma Sıcaklığı
- 110°C
- Additional Feature
- PA, UL 94V-0
- Akım
- 20A
- Yayın Yılı
- 2008
- Number Of Poles
- 2
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Number Of Ways
- 2
- Gerilim
- 600V
- HTS Kodu
- 8536.90.40.00
- Kurşunsuz
- Lead Free
- Montaj
- Through Hole
- RoHS Durumu
- RoHS Compliant
- Weight
- 7.319989g
- Uzunluk
- 47.7mm
- Max Current Rating
- 32A
- Voltageiec
- 1000V
- Renk
- Blue
- Tip
- Feed Through
- Nem Hassasiyeti (MSL)
- Not Applicable
- Flammability Rating
- UL94 V-0
- Number Of Decks
- 1
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Min
- 12 AWG
- Safety Approval
- UL; VDE; CSA
- Housing Material
- Polyamide
- Fabrika Tedarik Süresi
- 7 Weeks
- Contact Materials
- Copper
- Sıra Sayısı
- 2
- Parça Durumu
- Active
- Orientation
- Straight
- Seri
- CLIPLINE UT
- Yükseklik
- 55mm
- Terminal Stili
- Screw
