Volume pricing
- 1+ pcs$2.98
- 10+ pcs$2.81
- 100+ pcs$2.65
- 500+ pcs$2.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Number Of Ways
- 6
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 12 AWG
- Voltageiec
- 500V
- Material Insulation
- Polyamide (PA), Nylon
- Stripping Length
- 10mm
- Montaj
- Through Hole
- Safety Approval
- BV; CB; CSA; CUL; GL; GOST; LR
- Sıra Sayısı
- 2
- Terminal Stili
- Push In, Spring
- Uzunluk
- 91.5mm
- Seri
- CLIPLINE STTB
- Akım
- 20A
- Nominal Gerilim
- 500V
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 6
- Yayın Yılı
- 2010
- Wire Gauge Or Range Awg
- 12-28 AWG
- Kurşunsuz
- Lead Free
- Genişlik
- 5.2mm
- ECCN Kodu
- EAR99
- Gerilim
- 600V
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Max
- 28 AWG
- Additional Feature
- PA, UL 94V-0, SAFETY APPROVAL UL; VDE
- Number Of Levels
- 2; Connected
- Renk
- Gray
- Akım Değeri
- 26A
- Material Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.08-4mm2
- Currentiec
- 22A
- Number Of Decks
- 2
- Weight
- 15.199994g
- Fastening Method
- SPRING LOADED
- Tip
- Feed Through
- Wire Cross Section
- 4 mm2
- Fabrika Tedarik Süresi
- 4 Weeks
