Volume pricing
- 1+ pcs$0.71
- 10+ pcs$0.67
- 100+ pcs$0.63
- 500+ pcs$0.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 56mm
- Yükseklik
- 44mm
- Number Of Levels
- 1
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Or Range Mm
- 0.08-6mm2
- Yayın Yılı
- 2008
- Seri
- CLIPLINE ST
- Genişlik
- 6.2mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Renk
- Red
- Nominal Gerilim
- 800V
- Gerilim
- 600V
- Montaj
- Cable
- Material Flammability Rating
- UL94 V-0
- Wirecable Gauge
- 10 AWG
- Wire Gauge Min
- 10 AWG
- Fabrika Tedarik Süresi
- 7 Weeks
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 10mm
- Wire Gauge Or Range Awg
- 10-28 AWG
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Housing Material
- Polyamide
- HTS Kodu
- 8536.69.40.40
- Number Of Poles
- 2
- Flammability Rating
- UL94 V-0
- Tip
- Feed Through
- Akım
- 30A
- Weight
- 8.639999g
- Max Current Rating
- 40A
- Material Insulation
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Stili
- Push In, Spring
- Currentiec
- 32A
- Wire Gauge Max
- 28 AWG
- Akım Değeri
- 40A
