Volume pricing
- 1+ pcs$0.53
- 10+ pcs$0.50
- 100+ pcs$0.47
- 500+ pcs$0.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Insulation
- Polyamide (PA), Nylon
- Flammability Rating
- UL94 V-0
- Tip
- Feed Through
- Akım
- 15A
- Weight
- 4.93001g
- Max Current Rating
- 17.5A
- Akım Değeri
- 17.5A
- Terminal Stili
- Push In, Spring
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Max
- 26 AWG
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 500V
- Stripping Length
- 10mm
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 4 Weeks
- Housing Material
- Polyamide
- HTS Kodu
- 8536.69.40.40
- Number Of Poles
- 2
- Pozisyon Sayısı
- 2
- Wire Gauge Or Range Awg
- 14-26 AWG
- Onay Kuruluşu
- CB, CSA, VDE, cUL, cULus
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Genişlik
- 4.2mm
- Wirecable Gauge
- 16 AWG
- Wire Gauge Min
- 28 AWG
- Renk
- Black
- Nominal Gerilim
- 500V
- Gerilim
- 300V
- Montaj
- Cable
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 44mm
- Number Of Levels
- 1
- Uzunluk
- 48.5mm
- Seri
- CLIPLINE ST
- Yayın Yılı
- 2008
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Or Range Mm
- 0.08-1.5mm2
