Volume pricing
- 1+ pcs$2.88
- 10+ pcs$2.72
- 100+ pcs$2.57
- 500+ pcs$2.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 8-24 AWG
- Kurşunsuz
- Lead Free
- Housing Material
- Polyamide
- Pozisyon Sayısı
- 3
- Fabrika Tedarik Süresi
- 7 Weeks
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Stripping Length
- 12mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Terminal Stili
- Push In, Spring
- Wire Gauge Max
- 24 AWG
- Flammability Rating
- UL94 V-0
- Tip
- Ground, Earth
- Weight
- 29.200009g
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Yayın Yılı
- 2011
- Seri
- CLIPLINE ST
- Uzunluk
- 90.5mm
- Number Of Levels
- 1
- Yükseklik
- 51mm
- Renk
- Green, Yellow
- Nominal Gerilim
- 800V
- Montaj
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Wirecable Gauge
- 8 AWG
- Wire Gauge Min
- 8 AWG
- Genişlik
- 8.2mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
