Volume pricing
- 1+ pcs$1.65
- 10+ pcs$1.56
- 100+ pcs$1.47
- 500+ pcs$1.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- CLIPLINE STS
- Yayın Yılı
- 2011
- REACH Uyumluluk Kodu
- unknown
- Wire Gauge Or Range Mm
- 0.08-4mm2
- Yükseklik
- 50.5mm
- Number Of Levels
- 1
- Uzunluk
- 49mm
- Wirecable Gauge
- 12 AWG
- Wire Gauge Min
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Renk
- Green, Yellow
- Nominal Gerilim
- 800V
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Genişlik
- 5.2mm
- HTS Kodu
- 8536.69.40.40
- Pozisyon Sayısı
- 2
- Housing Material
- Polyamide
- Wire Gauge Or Range Awg
- 12-28 AWG
- Stripping Length
- 10mm
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Wire Gauge Max
- 28 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- Push In, Spring
- Material Insulation
- Polyamide (PA), Nylon
- Weight
- 11.289999g
- Flammability Rating
- UL94 V-0
- Tip
- Ground, Earth
