3036194

Specifications

Depth

16mm

Additional Feature

STANDARD: UL 94V-0, PA; SAFETY APPROVAL: EACEX; IECEX; KR; LR; NK; UL; VDE

Wire Gauge Or Range Mm

2.5-35mm2

Seri

CLIPLINE ST

Yayın Yılı

2005

Fastening Method

SPRING LOADED

Uzunluk

100mm

Safety Approval

ATEX; BV; CSA; CUL; DNVGL; EAC

Terminal Width

16.0mm

Number Of Levels

1

Yükseklik

66.5mm

Sıra Sayısı

1

Renk

Green, Yellow

Nominal Gerilim

8kV

Material Flammability Rating

UL94 V-0

Montaj

Through Hole

Wirecable Gauge

2 AWG

Number Of Decks

1

Wire Gauge Min

2 AWG

Genişlik

16mm

Kurşunsuz Kodu

yes

Parça Durumu

Active

Wire Gauge Or Range Awg

2-14 AWG

Number Of Ways

2

Onay Kuruluşu

CSA, UL, VDE, cULus

Housing Material

Polyamide

Number Of Poles

2

HTS Kodu

8536.69.40.40

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

4 Weeks

RoHS Durumu

RoHS Compliant

Stripping Length

25mm

Terminal Stili

Push In, Spring

Nem Hassasiyeti (MSL)

1 (Unlimited)

Wire Gauge Max

14 AWG

Akım Değeri

125A

Tip

Ground, Earth

Flammability Rating

UL94 V-0

Max Current Rating

125A

Weight

110.200011g
