3036165

Specifications

Terminal Width

12.2mm

Fastening Method

SPRING LOADED

Uzunluk

80mm

Safety Approval

UL; VDE; CSA

Sıra Sayısı

2

Number Of Levels

1

Yükseklik

58.5mm

Additional Feature

PA, UL 94V-0

Wire Gauge Or Range Mm

0.2-25mm2

Seri

CLIPLINE ST

Yayın Yılı

2011

Genişlik

12mm

Parça Durumu

Active

Kurşunsuz Kodu

yes

Material Flammability Rating

UL94 V-0

Montaj

Through Hole

Renk

Green, Yellow

Nominal Gerilim

8kV

Wirecable Gauge

4 AWG

Number Of Decks

1

Wire Gauge Min

24 AWG

ECCN Kodu

EAR99

Fabrika Tedarik Süresi

7 Weeks

Stripping Length

18mm

RoHS Durumu

RoHS Compliant

Number Of Ways

2

Onay Kuruluşu

CSA, UL, VDE, cULus

Wire Gauge Or Range Awg

4-16 AWG

Number Of Poles

2

HTS Kodu

8536.69.40.40

Housing Material

Polyamide

Max Current Rating

90A

Weight

51.200004g

Tip

Ground, Earth

Flammability Rating

UL94 V-0

Material Insulation

Polyamide (PA), Nylon

Wire Gauge Max

16 AWG

Terminal Stili

Push In, Spring

Nem Hassasiyeti (MSL)

1 (Unlimited)

Akım Değeri

76A
