Volume pricing
- 1+ pcs$1.36
- 10+ pcs$1.29
- 100+ pcs$1.21
- 500+ pcs$1.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2005
- Seri
- CLIPLINE ST
- Wire Gauge Or Range Mm
- 0.2-25mm2
- Additional Feature
- PA, UL 94V-0
- Sıra Sayısı
- 2
- Number Of Levels
- 1
- Yükseklik
- 58.5mm
- Terminal Width
- 12.2mm
- Safety Approval
- UL; VDE; CSA
- Fastening Method
- SPRING LOADED
- Uzunluk
- 80mm
- Number Of Decks
- 1
- Wire Gauge Min
- 16 AWG
- Wirecable Gauge
- 4 AWG
- Material Flammability Rating
- UL94 V-0
- Montaj
- Cable
- Gerilim
- 600V
- Nominal Gerilim
- 800V
- Renk
- Blue
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Genişlik
- 12mm
- Number Of Poles
- 2
- HTS Kodu
- 8536.69.40.40
- Housing Material
- Polyamide
- Kurşunsuz
- Lead Free
- Number Of Ways
- 2
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Wire Gauge Or Range Awg
- 4-16 AWG
- Stripping Length
- 18mm
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Akım Değeri
- 90A
- Wire Gauge Max
- 16 AWG
- Currentiec
- 76A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- Push In, Spring
- Material Insulation
- Polyamide (PA), Nylon
- Max Current Rating
- 90A
