Volume pricing
- 1+ pcs$9.10
- 10+ pcs$8.58
- 100+ pcs$8.10
- 500+ pcs$7.64
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Seri
- CLIPLINE STU
- Pozisyon Sayısı
- 5
- Renk
- Gray
- Nem Hassasiyeti (MSL)
- Not Applicable
- Nominal Gerilim
- 800V
- Wire Gauge Or Range Mm
- 1.5-50mm2
- ECCN Kodu
- EAR99
- Stripping Length
- 18mm
- Akım
- 115A
- Parça Durumu
- Active
- Wire Gauge Min
- 2 AWG
- Weight
- 60.690007g
- Wire Gauge Or Range Awg
- 2-14 AWG
- Yayın Yılı
- 2011
- Genişlik
- 16.2mm
- Material Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 7 Weeks
- Voltageiec
- 1000V
- REACH Uyumluluk Kodu
- unknown
- Kurşunsuz Kodu
- yes
- Currentiec
- 125A
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- Akım Değeri
- 125A
- Uzunluk
- 86mm
- Gerilim
- 600V
- Wire Gauge Max
- 14 AWG
- Material Insulation
- Polyamide (PA), Nylon
- Terminal
- Screw
- Terminal Stili
- Push In Spring; Screw
- Montaj
- Through Hole
- Tip
- Feed Through
