Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Gray
- Pozisyon Sayısı
- 5
- Seri
- CLIPLINE STI
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Disconnect Type
- Switch, Lever
- Onay Kuruluşu
- CSA, UL
- Wire Gauge Min
- 12 AWG
- Parça Durumu
- Active
- Akım
- 20A
- Stripping Length
- 10mm
- Wire Gauge Or Range Mm
- 0.08-4mm2
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 400V
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 5.2mm
- Yayın Yılı
- 2011
- Wire Gauge Or Range Awg
- 12-28 AWG
- Fabrika Tedarik Süresi
- 4 Weeks
- Number Of Levels
- 3; 1 Grounded
- Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Currentiec
- 24A
- Kurşunsuz Kodu
- yes
- Gerilim
- 300V
- Wire Gauge Max
- 28 AWG
- Material Insulation
- Polyamide (PA), Nylon
- Uzunluk
- 97mm
- Akım Değeri
- 24A
- Tip
- Disconnect, Feed Through, Isolated
- Terminal Stili
- Push In, Spring
