Volume pricing
- 1+ pcs$3.02
- 10+ pcs$2.85
- 100+ pcs$2.69
- 500+ pcs$2.54
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım
- 20A
- Genişlik
- 5.2mm
- Material Flammability Rating
- UL94 V-0
- Uzunluk
- 67.5mm
- Terminal
- Screw
- Terminal Stili
- Push In, Spring
- REACH Uyumluluk Kodu
- unknown
- Wirecable Gauge
- 12 AWG
- Sıra Sayısı
- 4
- Fastening Method
- SPRING LOADED
- Renk
- Gray
- Number Of Decks
- 2
- Wire Gauge Min
- 12 AWG
- Number Of Levels
- 2; Connected
- Number Of Ways
- 4
- Akım Değeri
- 26A
- Seri
- CLIPLINE STTB
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.08-4mm2
- Max Current Rating
- 22A
- Fabrika Tedarik Süresi
- 4 Weeks
- Stripping Length
- 10mm
- ECCN Kodu
- EAR99
- Housing Material
- Polyamide
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Awg
- 12-28 AWG
- Max Supply Voltage
- 500V
- Voltageiec
- 500V
- Number Of Circuits
- 1
- Gerilim
- 600V
- RoHS Durumu
- RoHS Compliant
- Weight
- 10.840007g
- Safety Approval
- CSA; CUL; GOST; UL
- Depth
- 5.2mm
- Wire Gauge Max
- 28 AWG
- Nominal Gerilim
- 500V
- Yayın Yılı
- 2011
- Kurşunsuz Kodu
- yes
- Tip
- Feed Through
- Parça Durumu
- Active
