Volume pricing
- 1+ pcs$2.70
- 10+ pcs$2.55
- 100+ pcs$2.40
- 500+ pcs$2.27
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 7 Weeks
- Stripping Length
- 10mm
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Awg
- 10-28 AWG
- Material Insulation
- Polyamide (PA), Nylon
- Number Of Poles
- 4
- RoHS Durumu
- RoHS Compliant
- Yükseklik
- 44mm
- Wire Cross Section
- 6 mm2
- Nem Hassasiyeti (MSL)
- Not Applicable
- Wire Gauge Max
- 28 AWG
- Weight
- 17.710004g
- Yayın Yılı
- 2008
- Nominal Gerilim
- 8kV
- Montaj
- Through Hole
- Parça Durumu
- Active
- Tip
- Ground, Earth
- Kurşunsuz Kodu
- yes
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 6.2mm
- Terminal Stili
- Push In, Spring
- Uzunluk
- 87mm
- Fastening Method
- SPRING LOADED
- Wirecable Gauge
- 10 AWG
- Number Of Levels
- 1
- Wire Gauge Min
- 10 AWG
- Renk
- Green, Yellow
- Kurşunsuz
- Lead Free
- Seri
- CLIPLINE ST
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Mm
- 0.08-6mm2
- Onay Kuruluşu
- CSA, UL, VDE, cULus
