Volume pricing
- 1+ pcs$1.23
- 10+ pcs$1.16
- 100+ pcs$1.09
- 500+ pcs$1.03
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Wire Gauge Or Range Mm
- 0.08-6mm2
- Flammability Rating
- UL94 V-0
- Seri
- CLIPLINE STTB
- Akım Değeri
- 32A
- Wire Gauge Min
- 10 AWG
- Number Of Levels
- 2
- Renk
- Blue
- Wirecable Gauge
- 10 AWG
- Fastening Method
- SPRING LOADED
- Terminal Stili
- Push In, Spring
- Uzunluk
- 83.5mm
- Material Flammability Rating
- UL94 V-0
- Akım
- 30A
- Genişlik
- 6.2mm
- Montaj
- Through Hole
- Kurşunsuz Kodu
- yes
- Tip
- Feed Through
- Parça Durumu
- Active
- Yayın Yılı
- 2008
- Nominal Gerilim
- 500V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Max
- 28 AWG
- Contact Materials
- Copper
- Weight
- 15.520003g
- RoHS Durumu
- RoHS Compliant
- Number Of Circuits
- 1
- Gerilim
- 600V
- Wire Gauge Or Range Awg
- 10-28 AWG
- Number Of Poles
- 4
- Material Insulation
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Stripping Length
- 10mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Max Current Rating
- 30A
