Specifications
- Wire Gauge Max
- 28 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Pozisyon Sayısı
- 4
- Weight
- 9.390014g
- Montaj
- Through Hole
- Tip
- Feed Through
- Parça Durumu
- Active
- Nominal Gerilim
- 800V
- Yayın Yılı
- 2008
- Number Of Contacts
- 4
- Terminal Width
- 5.2mm
- Stripping Length
- 10mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Currentul
- 20A
- Max Current Rating
- 28A
- RoHS Durumu
- RoHS Compliant
- Number Of Circuits
- 1
- Gerilim
- 600V
- Yükseklik
- 44mm
- Voltageiec
- 800V
- Wire Gauge Or Range Awg
- 12-28 AWG
- Number Of Poles
- 4
- Material Insulation
- Polyamide (PA), Nylon
- Housing Material
- Polyamide
- Currentiec
- 24A
- Kurşunsuz
- Lead Free
- Wire Gauge Min
- 12 AWG
- Number Of Levels
- 1
- Renk
- Blue
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Wire Gauge Or Range Mm
- 0.08-4mm2
- Flammability Rating
- UL94 V-0
- Seri
- CLIPLINE ST
- Akım Değeri
- 28A
- Terminal Stili
- Push In, Spring
- Uzunluk
- 72mm
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 5.2mm
- Akım
- 20A
- Wirecable Gauge
- 12 AWG
