Volume pricing
- 1+ pcs$0.52
- 10+ pcs$0.49
- 100+ pcs$0.46
- 500+ pcs$0.43
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Poles
- 2
- Material Insulation
- Polyamide (PA), Nylon
- Housing Material
- Polyamide
- Max Supply Voltage
- 500V
- Wire Gauge Or Range Awg
- 14-26 AWG
- Gerilim
- 300V
- Yükseklik
- 44mm
- RoHS Durumu
- RoHS Compliant
- Max Current Rating
- 17.5A
- Fabrika Tedarik Süresi
- 7 Weeks
- Stripping Length
- 10mm
- ECCN Kodu
- EAR99
- Nominal Gerilim
- 500V
- Yayın Yılı
- 2008
- Tip
- Feed Through
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Weight
- 8.120012g
- Wire Gauge Max
- 26 AWG
- Nem Hassasiyeti (MSL)
- Not Applicable
- Pozisyon Sayısı
- 4
- Depth
- 4.2mm
- Fastening Method
- SPRING LOADED
- Wirecable Gauge
- 16 AWG
- Genişlik
- 4.2mm
- Akım
- 15A
- Material Flammability Rating
- UL94 V-0
- Terminal Stili
- Push In, Spring
- Uzunluk
- 72mm
- Akım Değeri
- 17.5A
- Wire Gauge Or Range Mm
- 0.08-1.5mm2
- Flammability Rating
- UL94 V-0
- Seri
- CLIPLINE ST
- Onay Kuruluşu
- CB, CSA, UL, VDE, cULus
- Renk
- Gray
- Wire Gauge Min
- 14 AWG
- Number Of Levels
- 1
- Kurşunsuz
- Lead Free
