Specifications
- Wire Gauge Max
- 30 AWG
- Uzunluk
- 42.5mm
- Akım
- 20A
- Flammability Rating
- UL94 V-2
- Seri
- CLIPLINE UK
- HTS Kodu
- 8536.69.40.40
- Genişlik
- 5.2mm
- Nominal Gerilim
- 800V
- Onay Kuruluşu
- CB, CSA, KEMA, UL
- Wirecable Gauge
- 14 AWG
- Montaj
- Cable
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw
- Currentiec
- 24A
- Yayın Yılı
- 2011
- Sıra Sayısı
- 2
- Material Flammability Rating
- UL94 V-2
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 4 Weeks
- Tip
- Feed Through
- Gerilim
- 300V
- Stripping Length
- 7mm
- Akım Değeri
- 24A
- ECCN Kodu
- EAR99
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Number Of Levels
- 1
- Depth
- 5.2mm
- Renk
- Orange
- REACH Uyumluluk Kodu
- not_compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Yükseklik
- 49.5mm
- Wire Gauge Or Range Awg
- 12-30 AWG
- Weight
- 1.50003kg
- Wire Gauge Min
- 12 AWG
