Volume pricing
- 1+ pcs$6.34
- 10+ pcs$5.98
- 100+ pcs$5.64
- 500+ pcs$5.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 42.5mm
- Kurşunsuz Kodu
- yes
- Wire Gauge Max
- 24 AWG
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Seri
- CLIPLINE UK
- Genişlik
- 16.4mm
- Nominal Gerilim
- 400V
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw
- Wirecable Gauge
- 8 AWG
- Montaj
- Through Hole
- Tip
- Ground, Earth/Neutral
- Stripping Length
- 10mm
- Akım Değeri
- 57A
- Yayın Yılı
- 2011
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 4 Weeks
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 2
- Renk
- Blue, Green, Yellow
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Voltageiec
- 400V
- Material Insulation
- Polyamide (PA), Nylon
- Number Of Levels
- 1
- Wire Gauge Min
- 8 AWG
- Housing Material
- Polyamide
- Wire Gauge Or Range Awg
- 8-24 AWG
- Yükseklik
- 54.5mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Weight
- 46.729993g
