Specifications
- Terminal Width
- 15.0mm
- Max Current Rating
- 108A
- Housing Color
- Grey
- Safety Approval
- BV; DNV; GOST; GL; KEMP; LR
- Terminal Stili
- Screw
- Max Supply Voltage
- 1kV
- Weight
- 62.779991g
- HTS Kodu
- 8536.69.40.40
- Depth
- 15mm
- Number Of Decks
- 1
- Tip
- Feed Through
- Renk
- Gray
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 6 AWG
- Kurşunsuz
- Lead Free
- Material Flammability Rating
- UL94 V-0
- Number Of Ways
- 2
- Sıra Sayısı
- 2
- Additional Feature
- PA, UL 94V-0, SAFETY APPROVAL UL
- Housing Material
- Polyamide
- Uzunluk
- 57.5mm
- Yayın Yılı
- 2010
- Number Of Levels
- 1
- Nominal Gerilim
- 1kV
- Akım
- 85A
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Mm
- 6-25mm2
- Wire Gauge Min
- 10 AWG
- Parça Durumu
- Obsolete
- Flammability Rating
- UL94 V-0
- Stripping Length
- 17mm
- Gerilim
- 600V
- Genişlik
- 15mm
- Kurşunsuz Kodu
- yes
- Seri
- CLIPLINE UKH
- Voltageiec
- 1000V
- Montaj
- Cable
- Wire Gauge Or Range Awg
- 4-6 AWG
- Fabrika Tedarik Süresi
- 6 Weeks
- Material Insulation
- Polyamide (PA), Nylon
