Volume pricing
- 1+ pcs$6.69
- 10+ pcs$6.31
- 100+ pcs$5.95
- 500+ pcs$5.62
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2013
- Renk
- Gray
- Tip
- Disconnect
- RoHS Durumu
- RoHS Compliant
- Wire Gauge Max
- 26 AWG
- Material Flammability Rating
- UL94 V-2
- Terminal Width
- 8.2mm
- Pozisyon Sayısı
- 2
- Terminal Stili
- Screw
- Fabrika Tedarik Süresi
- 4 Weeks
- Material Insulation
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- Not Applicable
- Akım Değeri
- 6.3A
- Fuse Type
- 5mm x 20mm, 5mm x 25mm, 5mm x 30mm
- Seri
- CLIPLINE UK
- Voltageiec
- 500V
- Wire Gauge Or Range Awg
- 10-26 AWG
- Parça Durumu
- Active
- Disconnect Type
- Fuse, Lever
- Flammability Rating
- UL94 V-2
- Stripping Length
- 8mm
- Currentiec
- 6.3A
- Gerilim
- 600V
- Kurşunsuz Kodu
- yes
- Genişlik
- 8.2mm
- REACH Uyumluluk Kodu
- not_compliant
- Number Of Levels
- 1
- Akım
- 12A
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Wire Gauge Min
- 10 AWG
