Volume pricing
- 1+ pcs$1.13
- 10+ pcs$1.07
- 100+ pcs$1.01
- 500+ pcs$0.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Renk
- Blue
- Wire Gauge Or Range Mm
- 2.5-25mm2
- Wire Gauge Max
- 22 AWG
- Wire Gauge Or Range Awg
- 4-22 AWG
- HTS Kodu
- 8536.69.40.40
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Cable
- Gerilim
- 600V
- Max Supply Voltage
- 800V
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2005
- Genişlik
- 12.2mm
- Number Of Levels
- 1
- Seri
- CLIPLINE UK
- Depth
- 12.2mm
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw
- Yükseklik
- 54mm
- Wire Gauge Min
- 4 AWG
- Currentiec
- 76A
- Safety Approval
- UL; CSA
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 800V
- Wirecable Gauge
- 4 AWG
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 101A
- Pozisyon Sayısı
- 2
- Akım Değeri
- 101A
- Akım
- 85A
- Tip
- Feed Through
- Stripping Length
- 11mm
- Onay Kuruluşu
- CB, CSA, KEMA, UL, cULus
- Fabrika Tedarik Süresi
- 6 Weeks
- Lead Pitch
- 12.2mm
- Voltage Rated Ac
- 800V
- Uzunluk
- 42.5mm
- Housing Material
- Polyamide
- Nem Hassasiyeti (MSL)
- Not Applicable
- Material Insulation
- Polyamide (PA), Nylon
