Volume pricing
- 1+ pcs$5.87
- 10+ pcs$5.54
- 100+ pcs$5.23
- 500+ pcs$4.93
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 107mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Parça Durumu
- Active
- Weight
- 453.59237g
- Material Insulation
- Polyamide (PA), Nylon
- Akım
- 10A
- Fastening Method
- SPRING LOADED
- Stripping Length
- 10mm
- Tip
- Disconnect
- Flammability Rating
- UL94 V-0
- Voltageiec
- 400V
- Akım Değeri
- 16A
- Pozisyon Sayısı
- 4
- Currentiec
- 16A
- Wire Gauge Min
- 24 AWG
- Nominal Gerilim
- 400V
- Disconnect Type
- Switch, Knife
- Material Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Seri
- CLIPLINE ZDMTK
- Number Of Levels
- 2
- Genişlik
- 6.2mm
- Terminal Stili
- Push In, Spring
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2011
- Gerilim
- 300V
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Renk
- Gray
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Max
- 26 AWG
