Specifications
- Currentiec
- 57A
- Contact Materials
- Copper
- Number Of Contacts
- 1
- Number Of Decks
- 1
- Number Of Ways
- 2
- Tip
- Feed Through
- Onay Kuruluşu
- CSA, KEMA, UL, cULus
- Lead Pitch
- 10.2mm
- Voltage Rated Ac
- 800V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Housing Material
- Polyamide
- Parça Durumu
- Active
- Weight
- 16.800012g
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Max
- 24 AWG
- Housing Color
- Grey
- HTS Kodu
- 8536.90.40.00
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2001
- Gerilim
- 600V
- Max Supply Voltage
- 800V
- Number Of Levels
- 1
- Genişlik
- 10.2mm
- Terminal Stili
- Screw
- Voltage Rated Dc
- 800V
- Wire Gauge Min
- 6 AWG
- Yükseklik
- 52mm
- Safety Approval
- CSA; CUL; EAC; GL; RS; UL
- Material Flammability Rating
- UL94 V-0
- Wirecable Gauge
- 20 AWG
- Kurşunsuz
- Lead Free
- Flammability Rating
- UL94 V-0
- Max Current Rating
- 76A
- Akım Değeri
- 76A
- Reach Svhc
- No SVHC
- Akım
- 65A
- Stripping Length
- 10mm
- Fabrika Tedarik Süresi
- 13 Weeks
- Radyasyon Dayanımı
- No
- Uzunluk
- 42.5mm
