Volume pricing
- 1+ pcs$0.56
- 10+ pcs$0.53
- 100+ pcs$0.50
- 500+ pcs$0.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Or Range Awg
- 8-26 AWG
- Orientation
- Straight
- Renk
- Gray
- Sıra Sayısı
- 1
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Seri
- CLIPLINE UK
- Depth
- 8.2mm
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Akım Değeri
- 57A
- Max Current Rating
- 57A
- Flammability Rating
- UL94 V-0
- Wirecable Gauge
- 8 AWG
- Kurşunsuz
- Lead Free
- Material Flammability Rating
- UL94 V-0
- Nominal Gerilim
- 800V
- Safety Approval
- ABS; CCA; CSA; CUL; DNV; EAC
- Yükseklik
- 52mm
- Wire Gauge Min
- 8 AWG
- Radyasyon Dayanımı
- No
- Uzunluk
- 42.5mm
- Fabrika Tedarik Süresi
- 13 Weeks
- Stripping Length
- 10mm
- Akım
- 50A
- Max Supply Voltage
- 800V
- Gerilim
- 600V
- Kurşunsuz Kodu
- yes
- Yayın Yılı
- 2003
- HTS Kodu
- 8536.90.40.00
- Housing Color
- Grey
- Wire Gauge Max
- 26 AWG
- Ambalaj
- Bulk
- Terminal Stili
- Screw
- Genişlik
- 8.2mm
- Number Of Levels
- 1
- Pozisyon Sayısı
- 2
- Contact Materials
- Copper
- Currentiec
- 41A
- Weight
- 13.830003g
- Material Insulation
- Polyamide (PA), Nylon
