Volume pricing
- 1+ pcs$13.78
- 10+ pcs$13.00
- 100+ pcs$12.27
- 500+ pcs$11.57
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Özellikler
- LED
- Flammability Rating
- UL94 V-2
- Kurşunsuz
- Lead Free
- Voltageiec
- 500V
- Akım Değeri
- 10A
- Pozisyon Sayısı
- 2
- Wire Gauge Min
- 8 AWG
- Yükseklik
- 60.5mm
- Nominal Gerilim
- 500V
- Disconnect Type
- Fuse, Lever
- Material Flammability Rating
- UL94 V-2
- Safety Approval
- UL; CSA
- Uzunluk
- 79mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Parça Durumu
- Active
- Material Insulation
- Polyamide (PA), Nylon
- Weight
- 400.000006g
- Housing Material
- Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Decks
- 1
- Number Of Ways
- 2
- Akım
- 10A
- Onay Kuruluşu
- CSA, UL
- Stripping Length
- 12mm
- Tip
- Disconnect
- REACH Uyumluluk Kodu
- unknown
- Fuse Type
- 6.3mm x 32mm
- HTS Kodu
- 8536.90.40.00
- Yayın Yılı
- 2010
- Kurşunsuz Kodu
- yes
- Gerilim
- 600V
- Wire Gauge Or Range Mm
- 0.5-16mm2
- Sıra Sayısı
- 1
- Renk
- Black
- Wire Gauge Or Range Awg
- 8-26 AWG
- Wire Gauge Max
- 26 AWG
- Pitch
- 6.3mm
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Seri
- CLIPLINE UK
