Specifications
- Weight
- 1.099961kg
- Wire Gauge Min
- 14 AWG
- Parça Durumu
- Obsolete
- Akım
- 15A
- Stripping Length
- 9mm
- ECCN Kodu
- EAR99
- Wire Gauge Or Range Mm
- 0.14-2.5mm2
- Nominal Gerilim
- 800V
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 10.4mm
- Fastening Method
- SPRING LOADED
- Max Current Rating
- 24A
- Yayın Yılı
- 2011
- Wire Gauge Or Range Awg
- 14-26 AWG
- Renk
- Gray
- Pozisyon Sayısı
- 4
- Seri
- CLIPLINE MZDB
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Insulation
- Polyamide (PA), Nylon
- Wire Gauge Max
- 26 AWG
- Gerilim
- 600V
- Uzunluk
- 42.7mm
- Akım Değeri
- 24A
- Max Supply Voltage
- 800V
- Tip
- Feed Through
- Sıra Sayısı
- 2
- Safety Approval
- UL; CSA
- Terminal Stili
- Push In, Spring
- Number Of Levels
- 1
- Flammability Rating
- UL94 V-0
- Radyasyon Dayanımı
- No
- RoHS Durumu
- RoHS Compliant
- Currentiec
- 17.5A
