Volume pricing
- 1+ pcs$1.24
- 10+ pcs$1.17
- 100+ pcs$1.11
- 500+ pcs$1.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım
- 30A
- Tip
- Feed Through
- Gerilim
- 600V
- Fabrika Tedarik Süresi
- 14 Weeks
- Uzunluk
- 42.5mm
- ECCN Kodu
- EAR99
- Material Insulation
- Polyamide (PA), Nylon
- Sıra Sayısı
- 2
- Number Of Decks
- 1
- Number Of Levels
- 1
- Yükseklik
- 54.5mm
- Wirecable Gauge
- 10 AWG
- Wire Gauge Min
- 10 AWG
- Wire Gauge Max
- 30 AWG
- Seri
- CLIPLINE UK
- Stripping Length
- 8mm
- Nominal Gerilim
- 800V
- Akım Değeri
- 32A
- HTS Kodu
- 8536.69.40.40
- Pozisyon Sayısı
- 2
- Safety Approval
- CSA; UL
- Wire Gauge Or Range Awg
- 10-30 AWG
- Terminal Stili
- Screw
- Yayın Yılı
- 2008
- Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Material Flammability Rating
- UL94 V-0
- Currentiec
- 32A
- Onay Kuruluşu
- CB, CSA, KEMA, UL, cULus
- REACH Uyumluluk Kodu
- unknown
- Genişlik
- 6.2mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Voltageiec
- 800V
- Montaj
- Through Hole
- Wire Gauge Or Range Mm
- 0.2-6mm2
- Renk
- Orange
- Max Current Rating
- 30A
- Weight
- 8.699987g
