Volume pricing
- 1+ pcs$1.85
- 10+ pcs$1.75
- 100+ pcs$1.65
- 500+ pcs$1.55
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Material Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Onay Kuruluşu
- CSA, KEMA, UL, cULus
- REACH Uyumluluk Kodu
- unknown
- Genişlik
- 5.2mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Number Of Poles
- 3
- Voltageiec
- 400V
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj
- Through Hole
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Max Current Rating
- 24A
- Renk
- Blue
- Additional Feature
- POLYAMIDE, 94V-2
- Wire Cross Section
- 2.5 mm2
- Weight
- 10.559999g
- Tip
- Feed Through
- Akım
- 20A
- Fabrika Tedarik Süresi
- 4 Weeks
- Gerilim
- 150V
- Uzunluk
- 50.5mm
- Material Insulation
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Yükseklik
- 47mm
- Number Of Levels
- 1
- Wirecable Gauge
- 12 AWG
- Wire Gauge Min
- 12 AWG
- Wire Gauge Max
- 30 AWG
- Seri
- CLIPLINE UK
- Stripping Length
- 8mm
- Nominal Gerilim
- 400V
- Akım Değeri
- 24A
- Pozisyon Sayısı
- 3
- Safety Approval
- UL; CSA
- Wire Gauge Or Range Awg
- 12-30 AWG
- Terminal Stili
- Screw
- Yayın Yılı
- 2010
- Flammability Rating
- UL94 V-0
