Volume pricing
- 1+ pcs$11.94
- 10+ pcs$11.26
- 100+ pcs$10.63
- 500+ pcs$10.02
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım Değeri
- 30A
- Seri
- CLIPLINE UK
- Stripping Length
- 10mm
- Nominal Gerilim
- 250V
- Wire Gauge Or Range Awg
- 8-26 AWG
- Terminal Stili
- Screw
- Safety Approval
- UL; CSA
- Pozisyon Sayısı
- 2
- HTS Kodu
- 8536.90.40.00
- Yayın Yılı
- 2010
- Flammability Rating
- UL94 V-0
- Akım
- 30A
- Tip
- Disconnect
- Gerilim
- 300V
- Fabrika Tedarik Süresi
- 4 Weeks
- Yükseklik
- 52mm
- Number Of Levels
- 1
- Uzunluk
- 64mm
- ECCN Kodu
- EAR99
- Material Insulation
- Polyamide (PA), Nylon
- Wirecable Gauge
- 8 AWG
- Wire Gauge Min
- 8 AWG
- Wire Gauge Max
- 26 AWG
- Özellikler
- LED
- Voltageiec
- 250V
- Material
- Polyamide
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Montaj
- DIN Rail
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Black
- Max Current Rating
- 30A
- Weight
- 21.119998g
- Onay Kuruluşu
- CSA, UL
- Material Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Genişlik
- 8.2mm
- REACH Uyumluluk Kodu
- unknown
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Fuse Type
- Blade, C
