Volume pricing
- 1+ pcs$22.31
- 10+ pcs$21.05
- 100+ pcs$19.86
- 500+ pcs$18.73
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Weight
- 22.039997g
- Renk
- Black
- Max Current Rating
- 30A
- Wire Gauge Or Range Mm
- 0.2-10mm2
- Nem Hassasiyeti (MSL)
- Not Applicable
- Özellikler
- LED
- Housing Material
- Polyamide
- Disconnect Type
- Fuse, Removable Plug
- RoHS Durumu
- RoHS Compliant
- Fuse Type
- Blade, C
- Kurşunsuz Kodu
- yes
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- REACH Uyumluluk Kodu
- unknown
- Genişlik
- 8.2mm
- Material Flammability Rating
- UL94 V-0
- Orientation
- Straight
- Onay Kuruluşu
- CSA, UL
- Flammability Rating
- UL94 V-0
- Max Supply Voltage
- 250V
- Yayın Yılı
- 2011
- HTS Kodu
- 8536.69.40.40
- Safety Approval
- UL; CSA
- Pozisyon Sayısı
- 2
- Depth
- 8.2mm
- Terminal Stili
- Screw
- Wire Gauge Or Range Awg
- 8-26 AWG
- Seri
- CLIPLINE UK
- Nominal Gerilim
- 250V
- Stripping Length
- 10mm
- Akım Değeri
- 30A
- Wire Gauge Max
- 26 AWG
- Wire Gauge Min
- 8 AWG
- Wirecable Gauge
- 8 AWG
- Uzunluk
- 64mm
- Material Insulation
- Polyamide (PA), Nylon
- ECCN Kodu
- EAR99
- Number Of Levels
- 1
- Yükseklik
- 52mm
- Akım
- 30A
