Volume pricing
- 1+ pcs$2.43
- 10+ pcs$2.30
- 100+ pcs$2.17
- 500+ pcs$2.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 8 Weeks
- Number Of Circuits
- 1
- Tip
- Feed Through
- Weight
- 5.610002g
- Number Of Decks
- 2
- Akım Değeri
- 17.5A
- Wire Gauge Or Range Mm
- 0.14-1.5mm2
- Material Flammability Rating
- UL94 V-0
- Yükseklik
- 41mm
- Renk
- Blue
- Number Of Levels
- 2
- Onay Kuruluşu
- CSA, UL
- Wire Gauge Max
- 30 AWG
- Flammability Rating
- UL94 V-0
- Nem Hassasiyeti (MSL)
- Not Applicable
- ECCN Kodu
- EAR99
- Gerilim
- 300V
- Genişlik
- 4.2mm
- Wire Gauge Or Range Awg
- 14-30 AWG
- Housing Material
- Polyamide
- Yayın Yılı
- 2011
- RoHS Durumu
- RoHS Compliant
- Nominal Gerilim
- 400V
- Akım
- 15A
- Seri
- CLIPLINE MTTB
- Number Of Poles
- 4
- Uzunluk
- 44mm
- Max Supply Voltage
- 400V
- Terminal Stili
- Screw
- Safety Approval
- UL; CSA
- Montaj
- Cable
- Material Insulation
- Polyamide (PA), Nylon
- REACH Uyumluluk Kodu
- not_compliant
- Stripping Length
- 6mm
- Depth
- 4.2mm
- Max Current Rating
- 17.5A
- Wire Gauge Min
- 26 AWG
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
