2866747

Specifications

Fabrika Tedarik Süresi

7 Weeks

Montaj Tipi

DIN Rail

Montaj

DIN Rail

Max Output Current

3.5A

Min Input Voltage Dc

90V

Output Current

3.5A

Min Output Voltage

18V

Efficiency

88%

Nem Hassasiyeti (MSL)

Not Applicable

Pin Sayısı

12

Current Output1

3.5A

Seri

Quint

Yükseklik

130mm

Özellikler

Adjustable Output, DC Input Capable, IP20, Load Sharing, Universal Input

Number Of Outputs

1

Minimum Load Required

No

Max Input Voltage

264V

Onay Kuruluşu

CB, cULus, cURus

Weight

499.858792g

Çalışma Sıcaklığı

-25°C~70°C With Derating

Max Output Voltage

29.5V

Boyut / Ölçü

4.92Lx1.26W x 5.12 H 125.0mmx32.0mmx130.0mm

Tip

Enclosed

Max Voltage Rating Ac

264V

Parça Durumu

Active

Depth

130mm

Applications

ITE (Commercial)

Max Input Voltage Dc

350V

Output Power

84W

Yayın Yılı

2008

Voltage Isolation

4kV

Min Input Voltage

85V

RoHS Durumu

RoHS Compliant

Nominal Input Voltage Ac

240V

Min Input Voltage Ac

85V

Max Power Dissipation

84W
