Volume pricing
- 1+ pcs$4.70
- 10+ pcs$4.44
- 100+ pcs$4.19
- 500+ pcs$3.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Voltageiec
- 500V
- Gerilim
- 300V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Min
- 24 AWG
- Safety Approval
- UL; CSA
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Sıra Sayısı
- 2
- REACH Uyumluluk Kodu
- not_compliant
- Kurşunsuz Kodu
- yes
- Akım
- 20A
- Weight
- 1.099961kg
- Wire Gauge Max
- 30 AWG
- Wire Gauge Or Range Awg
- 12-30 AWG
- Flammability Rating
- UL94 V-2
- Pozisyon Sayısı
- 4
- Yayın Yılı
- 2010
- ECCN Kodu
- EAR99
- Akım Değeri
- 24A
- Material Insulation
- Polyamide (PA), Nylon
- Kurşunsuz
- Lead Free
- Montaj
- Through Hole
- Seri
- CLIPLINE MBKKB
- Uzunluk
- 62mm
- Material Flammability Rating
- UL94 V-2
- Onay Kuruluşu
- UL, cULus
- Renk
- Gray
- Parça Durumu
- Active
- Terminal Stili
- Screw
- Fabrika Tedarik Süresi
- 7 Weeks
- Tip
- Feed Through
- RoHS Durumu
- RoHS Compliant
- Currentiec
- 24A
- Wirecable Gauge
- 12 AWG
- Genişlik
- 5.2mm
- Number Of Decks
- 2
- Number Of Levels
- 2; Connected
- Stripping Length
- 7mm
- Nominal Gerilim
- 500V
