Volume pricing
- 1+ pcs$5.35
- 10+ pcs$5.04
- 100+ pcs$4.76
- 500+ pcs$4.49
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Min
- 10 AWG
- Housing Color
- Green
- Uzunluk
- 63.5mm
- Yükseklik
- 52.5mm
- Depth
- 6.2mm
- Sıra Sayısı
- 2
- Safety Approval
- UL
- Yayın Yılı
- 2008
- Max Current Rating
- 32A
- Number Of Poles
- 4
- RoHS Durumu
- RoHS Compliant
- Genişlik
- 6.2mm
- Orientation
- Straight
- Wire Gauge Or Range Mm
- 0.2-6mm2
- Wire Gauge Or Range Awg
- 10-22 AWG
- Kurşunsuz
- Lead Free
- Onay Kuruluşu
- CSA, UL, cULus
- Wire Gauge Max
- 22 AWG
- Seri
- CLIPLINE UDK
- Material Insulation
- Polyamide (PA), Nylon
- Stripping Length
- 8mm
- Number Of Ways
- 4
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 1
- Material Flammability Rating
- UL94 V-2
- Max Supply Voltage
- 690V
- Akım Değeri
- 32A
- Number Of Decks
- 2
- Tip
- Ground, Earth
- Housing Material
- Polyamide
- Renk
- Green, Yellow
- Fabrika Tedarik Süresi
- 7 Weeks
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Weight
- 28.349523g
- ECCN Kodu
- EAR99
- Radyasyon Dayanımı
- No
- Flammability Rating
- UL94 V-2
- Wire Cross Section
- 6 mm2
- Wirecable Gauge
- 10 AWG
