Volume pricing
- 1+ pcs$0.70
- 10+ pcs$0.66
- 100+ pcs$0.62
- 500+ pcs$0.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Currentul
- 35A
- Gerilim
- 600V
- Genişlik
- 6.2mm
- Voltageiec
- 630V
- Safety Approval
- UL
- Yayın Yılı
- 2008
- Max Current Rating
- 32A
- Number Of Poles
- 4
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 63.5mm
- Yükseklik
- 52.5mm
- Sıra Sayısı
- 2
- Wire Gauge Min
- 10 AWG
- Nominal Gerilim
- 630V
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 1
- Material Flammability Rating
- UL94 V-2
- Onay Kuruluşu
- CSA, UL, cULus
- Wire Gauge Max
- 30 AWG
- Seri
- CLIPLINE UDK
- Material Insulation
- Polyamide (PA), Nylon
- Stripping Length
- 8mm
- Number Of Ways
- 4
- Kurşunsuz
- Lead Free
- Wire Gauge Or Range Mm
- 0.2-6mm2
- Orientation
- Straight
- Wire Gauge Or Range Awg
- 10-30 AWG
- Akım Değeri
- 32A
- Number Of Decks
- 2
- Tip
- Feed Through
- Housing Material
- Nylon
- Wirecable Gauge
- 10 AWG
- Terminal Stili
- Screw
- Montaj
- Through Hole
- Flammability Rating
- UL94 V-2
- Akım
- 30A
- Parça Durumu
- Active
- Weight
- 15.499988g
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 13 Weeks
