Volume pricing
- 1+ pcs$0.75
- 10+ pcs$0.70
- 100+ pcs$0.66
- 500+ pcs$0.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polyamide
- Tip
- Feed Through
- Akım Değeri
- 32A
- Max Supply Voltage
- 690V
- REACH Uyumluluk Kodu
- not_compliant
- Flammability Rating
- UL94 V-2
- Terminal Stili
- Screw
- Wirecable Gauge
- 10 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Renk
- Gray
- Fabrika Tedarik Süresi
- 13 Weeks
- Weight
- 15.370006g
- ECCN Kodu
- EAR99
- Akım
- 30A
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Number Of Poles
- 4
- Max Current Rating
- 32A
- Yayın Yılı
- 2008
- Safety Approval
- UL; CSA
- Voltageiec
- 630V
- Genişlik
- 6.2mm
- Ambalaj
- Bulk
- Gerilim
- 600V
- Housing Color
- Grey
- Nominal Gerilim
- 630V
- Wire Gauge Min
- 10 AWG
- Yükseklik
- 52.5mm
- Depth
- 6.2mm
- Uzunluk
- 63.5mm
- Material Insulation
- Polyamide (PA), Nylon
- Seri
- CLIPLINE UDK
- Stripping Length
- 8mm
- Number Of Ways
- 4
- Onay Kuruluşu
- CSA, UL, cULus
- Wire Gauge Max
- 30 AWG
- Material Flammability Rating
- UL94 V-2
- Number Of Levels
- 1
- Wire Gauge Or Range Awg
- 10-30 AWG
- Wire Gauge Or Range Mm
- 0.2-6mm2
