Volume pricing
- 1+ pcs$2.98
- 10+ pcs$2.81
- 100+ pcs$2.65
- 500+ pcs$2.50
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Akım
- 20A
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Weight
- 14.089996g
- Fabrika Tedarik Süresi
- 7 Weeks
- Renk
- Blue
- Wirecable Gauge
- 12 AWG
- Terminal Stili
- Screw
- Number Of Circuits
- 1
- Flammability Rating
- UL94 V-0
- Akım Değeri
- 32A
- Number Of Decks
- 2
- Tip
- Feed Through
- Wire Gauge Or Range Mm
- 0.2-4mm2
- Wire Gauge Or Range Awg
- 12-28 AWG
- Kurşunsuz Kodu
- yes
- Number Of Levels
- 2
- Material Flammability Rating
- UL94 V-0
- Onay Kuruluşu
- CSA, UL, cULus
- Wire Gauge Max
- 28 AWG
- Seri
- CLIPLINE UKKB
- Material Insulation
- Polyamide (PA), Nylon
- Stripping Length
- 8mm
- Number Of Ways
- 4
- Uzunluk
- 67mm
- Yükseklik
- 62mm
- Sıra Sayısı
- 1
- Wire Gauge Min
- 12 AWG
- Nominal Gerilim
- 500V
- Gerilim
- 600V
- Genişlik
- 5.2mm
- Safety Approval
- UL
- Yayın Yılı
- 2011
- Max Current Rating
- 32A
- Number Of Poles
- 4
- RoHS Durumu
- RoHS Compliant
