Volume pricing
- 1+ pcs$4.32
- 10+ pcs$4.08
- 100+ pcs$3.85
- 500+ pcs$3.63
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Kurşunsuz Kodu
- yes
- Akım
- 15A
- Weight
- 600.102706g
- Wire Gauge Max
- 30 AWG
- Flammability Rating
- UL94 V-2
- Wire Gauge Or Range Awg
- 14-30 AWG
- Yayın Yılı
- 2010
- ECCN Kodu
- EAR99
- Akım Değeri
- 24A
- Yükseklik
- 70mm
- Material Insulation
- Polyamide (PA), Nylon
- Kurşunsuz
- Lead Free
- Number Of Contacts
- 6
- Voltageiec
- 250V
- Housing Material
- Nylon
- Gerilim
- 300V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Wire Gauge Min
- 24 AWG
- Safety Approval
- UL; CSA
- Orientation
- Straight
- Wire Gauge Or Range Mm
- 0.2-4mm2
- REACH Uyumluluk Kodu
- unknown
- Fabrika Tedarik Süresi
- 7 Weeks
- Tip
- Feed Through (2), Isolated (2)
- RoHS Durumu
- RoHS Compliant
- Currentiec
- 24A
- Wirecable Gauge
- 12 AWG
- Genişlik
- 6.2mm
- Stripping Length
- 8mm
- Number Of Levels
- 4
- Nominal Gerilim
- 250V
- Reach Svhc
- No SVHC
- Seri
- CLIPLINE VIOK
- Uzunluk
- 73mm
- Material Flammability Rating
- UL94 V-2
- Onay Kuruluşu
- CSA, UL, cULus
- Renk
- Gray
- Max Current Rating
- 26A
- Housing Color
- Grey
- Parça Durumu
- Active
