Volume pricing
- 1+ pcs$14.07
- 10+ pcs$13.28
- 100+ pcs$12.52
- 500+ pcs$11.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 4 Weeks
- Sıra Sayısı
- 1
- Yayın Yılı
- 2011
- Genişlik
- 32mm
- Flammability Rating
- UL94 HB
- Wire Gauge Or Range Mm
- 16-50mm2
- Wire Gauge Or Range Awg
- 1/0-6 AWG
- Akım Değeri
- 150A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Stripping Length
- 26mm
- RoHS Durumu
- RoHS Compliant
- Number Of Ways
- 2
- Voltageiec
- 1000V
- Renk
- Gray
- Tip
- Feed Through
- Safety Approval
- UL
- Kurşunsuz Kodu
- yes
- Wire Gauge Min
- 0 AWG
- Terminal
- Screw
- Wire Gauge Max
- 6 AWG
- Material Flammability Rating
- UL94 HB
- HTS Kodu
- 8536.69.40.40
- Nominal Gerilim
- 1kV
- Uzunluk
- 104mm
- Terminal Width
- 32.0mm
- Terminal Stili
- Bolt and Nut, Screw
- Number Of Decks
- 1
- ECCN Kodu
- EAR99
- Gerilim
- 600V
- Seri
- CLIPLINE UHV
- Additional Feature
- PA, 94-HB
- Akım
- 150A
- Fastening Method
- SPECIAL AND HYBRID
- Number Of Levels
- 1
- Pozisyon Sayısı
- 2
- Material Insulation
- Polyamide (PA), Nylon, Glass Filled
- Weight
- 171.030008g
