Volume pricing
- 1+ pcs$2.76
- 10+ pcs$2.61
- 100+ pcs$2.46
- 500+ pcs$2.32
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Ways
- 12
- REACH Uyumluluk Kodu
- unknown
- Number Of Poles
- 12
- Yayın Yılı
- 2008
- Nominal Gerilim
- 250V
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 24A
- Wire Gauge Max
- 26 AWG
- Number Of Levels
- 1
- Fabrika Tedarik Süresi
- 10 Weeks
- Renk
- Green
- Depth
- 12.8mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Interlocking (Side)
- Safety Approval
- UL
- Weight
- 12.249999g
- Pitch
- 0.197 5.00mm
- Flammability Rating
- UL94 V-0
- Wire Gauge Min
- 12 AWG
- Gerilim
- 300V
- Housing Material
- Polyamide (PA), Nylon
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Screw Thread
- M2.6
- Number Of Decks
- 1
- Additional Feature
- PA, UL 94V-0
- Wire Termination
- Screw
- Kurşunsuz
- Lead Free
- Max Current Rating
- 24A
- Wire Gauge
- 12-26 AWG
- Onay Kuruluşu
- CB, UL, VDE
- Wire Cross Section
- 2.5 mm2
- Material
- Polyamide
- Mating Orientation
- 45° (135°) Angle with Board
- Akım
- 15A
- Max Supply Voltage
- 250V
- Genişlik
- 12.8mm
- Seri
- COMBICON PTA
- ECCN Kodu
- EAR99
