Volume pricing
- 1+ pcs$0.89
- 10+ pcs$0.84
- 100+ pcs$0.79
- 500+ pcs$0.75
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2004
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Bulk
- Akım
- 65A
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Contact Materials
- Tin
- Max Current Rating
- 76A
- Number Of Contacts
- 1
- Flammability Rating
- UL94 V-0
- Housing Material
- Polyamide (PA), Nylon
- Additional Feature
- PA, UL 94V-0
- Pitch
- 15mm
- Wire Termination
- Screwless - Spring Cage, Tension Clamp
- Safety Approval
- UL
- Parça Durumu
- Active
- Material
- Polyamide
- Wire Gauge Max
- 24 AWG
- Nominal Gerilim
- 1kV
- Number Of Ways
- 1
- Weight
- 907.18474g
- Mating Orientation
- 45° (135°) Angle with Board
- Seri
- COMBICON ZFKDS
- Sıra Sayısı
- 1
- Gender
- Female
- Yükseklik
- 27mm
- Renk
- Green
- Gerilim
- 600V
- Özellikler
- Interlocking (Side)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.69.40.40
- Fastening Method
- SPRING LOADED
- Uzunluk
- 33.4mm
- Terminal
- Screwless
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 1
- Wire Gauge Min
- 6 AWG
- Wire Gauge
- 6-24 AWG
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
