Volume pricing
- 1+ pcs$1.45
- 10+ pcs$1.37
- 100+ pcs$1.29
- 500+ pcs$1.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Parça Durumu
- Active
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Montaj
- Through Hole
- Fabrika Tedarik Süresi
- 7 Weeks
- Number Of Ways
- 12
- Flammability Rating
- UL94 V-0
- Uzunluk
- 7.6mm
- Ambalaj
- Bulk
- Özellikler
- Interlocking (Side)
- Nominal Gerilim
- 160V
- Yayın Yılı
- 2005
- Kurşunsuz Kodu
- yes
- Wire Gauge
- 16-26 AWG
- HTS Kodu
- 8536.69.40.40
- Weight
- 5.519992g
- Number Of Contacts
- 12
- Housing Material
- Polyamide (PA), Nylon
- Kurşunsuz
- Lead Free
- Stripping Length
- 5mm
- ECCN Kodu
- EAR99
- Max Current Rating
- 17.5A
- Yükseklik
- 9mm
- Pitch
- 0.138 3.50mm
- Wire Gauge Max
- 26 AWG
- Seri
- COMBICON PT
- Gerilim
- 300V
- Screw Thread
- M2
- Safety Approval
- UL
- Number Of Levels
- 1
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Wire Termination
- Screw
- Akım Değeri
- 17.5A
- Insulation Materials
- Nylon
- Onay Kuruluşu
- UL
- Mating Orientation
- Horizontal with Board
- Sıra Sayısı
- 1
- Renk
- Green
- Wire Gauge Min
- 26 AWG
