Volume pricing
- 1+ pcs$3.94
- 10+ pcs$3.72
- 100+ pcs$3.51
- 500+ pcs$3.31
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Insulation Height
- 0.591 15.00mm
- Akım Değeri
- 12A
- Renk
- Green
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Housing Material
- Polyamide (PA), Nylon
- Currentiec
- 12A
- Yayın Yılı
- 2011
- Sıra Sayısı
- 1
- Weight
- 1.50003kg
- Pitch
- 0.197 5.00mm
- Material
- Polyamide, Tin
- Tip
- Plug, Female Sockets
- Özellikler
- Retention Latches (Non-Wire Side)
- Terminal
- Screwless
- Montaj
- Free Hanging
- Fastening Method
- SPRING LOADED
- Ambalaj
- Bulk
- Additional Feature
- PA, UL 94V-0
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Wire Strip Length
- 10mm
- Number Of Levels
- 1
- Wire Gauge Min
- 24 AWG
- Gerilim
- 300V
- Seri
- COMBICON FKCS
- Flammability Rating
- UL94 V-0
- Wire Gauge Or Range Awg
- 12-26 AWG
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Akım
- 10A
- Plug Wire Entry
- 180°
- Number Of Ways
- 5
- ECCN Kodu
- EAR99
- Number Of Positions Per Level
- 5
- Voltageiec
- 630V
- Safety Approval
- UL
- Montaj Tipi
- Free Hanging (In-Line)
- Wire Gauge Max
- 12 AWG
- Material Flammability Rating
- UL94 V-0
- Gender
- Female
- Contact Mating Finish
- Tin
