Volume pricing
- 1+ pcs$17.88
- 10+ pcs$16.86
- 100+ pcs$15.91
- 500+ pcs$15.01
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Currentiec
- 12A
- Tip
- Plug, Female Sockets
- Renk
- Green
- Özellikler
- Mating Flange, Retention Latches (Non-Wire Side)
- Material Flammability Rating
- UL94 V-0
- Number Of Levels
- 1
- ECCN Kodu
- EAR99
- Seri
- COMBICON SMSTB
- Contact Mating Finish
- Tin
- Number Of Decks
- 1
- Kurşunsuz Kodu
- yes
- Nominal Gerilim
- 250V
- Montaj Tipi
- Free Hanging (In-Line)
- Insulation Height
- 0.610 15.49mm
- Terminal Stili
- Screw - Rising Cage Clamp
- HTS Kodu
- 8536.69.40.40
- Number Of Ways
- 15
- Number Of Positions Per Level
- 15
- Wire Gauge Or Range Awg
- 12-30 AWG
- Wire Gauge Min
- 12 AWG
- Sıra Sayısı
- 1
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Bulk
- Wire Gauge Max
- 30 AWG
- Voltageiec
- 630V
- Flammability Rating
- UL94 V-2
- Plug Wire Entry
- 45°
- Pitch
- 0.197 5.00mm
- Depth
- 15.5mm
- Gerilim
- 300V
- Wire Strip Length
- 7mm
- Housing Material
- Polyamide (PA), Nylon
- Fabrika Tedarik Süresi
- 6 Weeks
- Connector Type
- Screw
- Material
- Polyamide, Tin
- Parça Durumu
- Active
- Montaj
- Free Hanging
- Yayın Yılı
- 2011
- Wire Gauge Or Range Mm
- 0.2-2.5mm2
- Screw Size
- M3
