Volume pricing
- 1+ pcs$8.38
- 10+ pcs$7.91
- 100+ pcs$7.46
- 500+ pcs$7.04
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Renk
- Green
- Currentiec
- 76A
- Number Of Ways
- 4
- Safety Approval
- UL
- Insulation Height
- 1.094 27.80mm
- Montaj Tipi
- Free Hanging (In-Line)
- Kurşunsuz Kodu
- yes
- Number Of Decks
- 1
- Wire Strip Length
- 12mm
- Depth
- 27.8mm
- Orientation
- Straight
- Flammability Rating
- UL94 V-0
- Plug Wire Entry
- 180°
- Wire Gauge Max
- 20 AWG
- Material
- Polyamide
- Parça Durumu
- Active
- Connector Type
- Screw
- Fabrika Tedarik Süresi
- 4 Weeks
- Housing Material
- Polyamide (PA), Nylon
- Contact Mating Finish
- Silver
- Seri
- COMBICON IPC
- Number Of Levels
- 1
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 44.1mm
- Özellikler
- Mating Flange
- Tip
- Plug, Male Pins
- RoHS Durumu
- RoHS Compliant
- Sıra Sayısı
- 1
- Wire Gauge Min
- 6 AWG
- Wire Gauge Or Range Awg
- 6-20 AWG
- Number Of Positions Per Level
- 4
- Terminal Stili
- Screw - Rising Cage Clamp
- REACH Uyumluluk Kodu
- not_compliant
- Nominal Gerilim
- 1kV
- Gerilim
- 600V
- Pitch
- 0.400 10.16mm
- Voltageiec
- 1kV
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
